The Penguinr/c P2020 Performance Chassis is is designed to enhance the already stellar performance characteristics of the current Tamiya TA05. The P2020 is comprised of a specially designed dual deck chassis which increases the stiffness of the base car by eliminating many of the flexible plastic components with high strength lightweight quasi-grade graphite plate.

Top Bottom
click on picture for larger view

This kit includes all the plates and hardware that you need for conversion. Advancements that have been incorporated into this conversion kit include changes in the battery placement to place more weight toward the front of the car for better steering response and improved balance through high speed corners. Adjustments have been made to the steering ackerman to improve steering linearity for a smoother driving experience. Motor protection is provided with a raised graphite brace to protect the endbell and a special milled chassis for improved motor cooling to keep power to the wheels.

Steering Motor Protection
click on picture for larger view

Optional for this chassis are specially designed quasi-grade graphite shock towers that increase the linearity and amount of adjustment availible to the TA05. Both the front (P2026) and the rear (P2027) shock towers include 5 shock angle adjustments arranged upon the shock arc so that changes in shock angle do not adversely affect vehicle ride height. This allows for quicker changes to the suspension dampening allowing for more track time and less time in the pits. Additionally the rear shock tower includes a graphite body mount plate that retains the stock Tamiya mounting locations to ease conversion from the TA05 to the P2020.

Front Shock Tower Rear Shock Tower
click on picture for larger view

Further options for the P2020 include a Graphite Front Bumper Brace (P2028), Graphite Steering Drag Link (P2023), and specialized Rear Toe Adjustment Plates (P2027t1 or 2). The P2028 front bumper brace provides more strength to the front of the vehicle. This allows minor collisions to have little, to no effect on the body helping to retain consistent aerodynamics and fewer DNF's due to vehicle damage. The special P2020 rear toe plate kits are availible in two sets. One set contains plates to adjust the static rear toe at the chassis to 0°, 1°, and 2° (P2027t1) where the second set provides plates that adjust toe settings to -.5°, .5° and 1.5° (P2027t2). Both of these kits allow you to adjust the characteristics that the P2020 has when entering and exiting a corner by altering the rear steer characteristics the vehicle exibits.

Bumper Toe
click on picture for larger view

Side Veiw

List Price: $122.99
Part Number: P2020


Purchase P2300



P2020 Replacement Parts List:


P2021
P2022
P2023a
P2024
P2025
P2029a

P2020 Graphite Main Chassis Plate
P2020/TA05 Graphite Upper Deck Plate
P2020 Steering Parts Kit
P2020 Motor Spacer Kit
P2020 Graphite Motor Guard
P2020 Standard Battery Mount Kit

$85.99
$43.99
$11.99
$10.99
$14.99
$12.99

$
$
$
$
$
$

P2020 Option Parts List:


P2023
P2026
P2027
P2027t1
P2027t2
P2028
P2028s
P2029b

P2020/TA05 Graphite Steering Drag Link
P2020/TA05 Graphite Front Shock Tower
P2020/TA05 Graphite Rear Shock Tower
P2020 Rear Toe Plate Kit (0°, 1°, 2°)
P2020 Rear Toe Plate Kit (-.5°, .5°, 1.5°)
P2020/TA05 Front Bumper Brace
P2020/TA05 Front Splitter Kit
P2020 Velcro
Battery Mount Kit

$6.99
$16.99
$19.99
$.tbd
$.tbd
$17.99
$25.99
$12.99

$
$
$
$
$
$
$
$

Click on blue $ to add replacement parts to your PayPal web cart.


Click here to Download Direction Manual:


If you have any questions or comments regarding this chassis conversion please feel free to mail us at support@penguinrc.com
