The Penguinr/c P3500 Micro RS4 Performance Chassis is designed to improve on the immensly successful platform of the Micro RS4. As many users of the micro know this car can be one potent little race car. Our goal in producing this chassis set was to capture the ultimate potential of the micro and allow the user to be able to vastly tune the car for any track surface. We have developed a whole new chassis for the micro which incorporates some revolutionary new features and performance for a car of this size.

Top Bottom
click on picture for larger view

The newly developed rear roll system is one of a kind in this class of car. This roll system retains a completely flat chassis while providing maximum rear pod adjustability. The advantages of this system include the ability to adjust the rear of the car to gain or reduce traction or roll according to the track surface and driving style of the user. There are a total of 12 plates that are available (4 soft, 4 medium, and 4 hard). In each set there are 2 pairs of plates, one made from G10 Fiberglass and the other from Quasi-Grade Plate consisting of a low and high roll option for each material. The 3 graphite high roll plates are included with the standard P3500 chassis kit. All the plates are also available separately in G10 and Graphite, Low and High roll Sets.

Roll Pod
click on picture for larger view

At the rear of the P3500 we designed a new deck system. This graphite rear deck allows use of any style shock currently on the market. This innovative deck allows the use of aftermarket oil filled shocks with either wheelbase setting without having to readjust any shock settings (when shock length is the same as stock).

Top Bottom
click on picture for larger view

In addition to all of the features mentioned above, the P3500's lower chassis is mounted .5mm lower eliminating the belt friction associated with the standard Micro. The P3500 includes a quick release center battery mounting plate to allow use of many different style batteries packs without interfearing with the belt. This plate P3505 can be purchased separately to allow mounting of several packs before installation in the P3500.

The P3500, in 150mm mode, allows adjustment of the center mount battery pack to two different positions for weight balance. The 150mm mode also allows the option of using the standard size HPI Upper Deck or our Standard Upper Deck Option (P3502s) when using the 150mm format. Using one of these decks will retain the use of the standard HPI Battery mounting System.

The P3500 chassis kit includes Upper, Lower, and Rear Chassis Plates made out of M1.5 Quasi-Grade woven carbon graphite plate, M2.0 Rear Pod Plate, P3507a High Roll Plate Set (3 Graphite roll plates), P3505 M3.0 G10 Battery Plate, Directions, and all hardware required to convert your Micro RS4 to the P3500.


List Price: $54.99
Part Number: P3500


Purchase P3500

Pictures shown may differ slightly from Actual P3500.


Now Availible
for a limited time...
P3500/lm Special Edition in
Ice Blue or Silver SSG Style Graphite.

click here to see the special edition...


P3500 Replacement Parts List:

P3501
P3502
P3503
P3504
P3505
P3507a
P3500 Main Chassis (narrow)
P3500 Upper Deck
P3500/Micro Rear Deck Kit
(VCS compatible)
P3500 Rear Pod Kit
P3500 Center Battery Plate
P3500 Graphite High Roll Plate Set
$23.99
$8.99
$24.99
$12.99
$3.99
$8.99
$
$
$
$
$
$

P3500 Option Parts List:

P3501lm
P3502s
P3502v
P3504l
P3505
P3506a
P3506b
P3507a
P3507b
P3508
P3508m180
P3508m300
P3508m400
P3500lm Main Chassis (wide)
P3500/Micro Upper Deck (standard)
P3500 Vertical Upper Deck (no hardware)
P3500 Rear Pod Kit for 400 Motor
P3500 Center Battery Plate
P3500 G10 High Roll Plate Set
P3500 G10 Low Roll Plate Set
P3500 Graphite High Roll Plate Set
P3500 Graphite Low Roll Plate Set
P3500/Micro Micro Servo Mount
P3500/Micro Graphite Motor Plate (180 size)
P3500/Micro Graphite Motor Plate (300 size)
P3500/Micro Graphite Motor Plate (400 size)
$33.99
$10.99
$10.99
$16.99
$3.99
$8.99
$8.99
$8.99
$8.99
$3.99
$5.99
$5.99
$5.99
$
$
$
$
$
$
$
$
$
$
$
$
$

Click on blue $ to add replacement parts to your PayPal web cart.


Click here to Download Direction Manual:


If you have any questions or comments regarding this chassis conversion please feel free to mail us at support@penguinrc.com
