Setup Sheet

Driver - Mike Collins
Date - June 15&16 2002
Track Location - HPI Challenge Chicago
Track Type - Asphault
Track Notes:
Old Parking Lot, Bumpy
Results: 1st A-main Time: 18/5:03
Fast Lap: 15.0

Car Information

Brand: HPI
Model: Pro3
Body: HPI Dodge Stratus
Wing: Standard
Motor Brand: Integy
Motor Type: Matrix 9.0 9x2
Gearing: 120/32
Battery/Fuel: VESC GP3000


Options Installed:
Notes:
Penguin r/c P3000
Penguin r/c P3010





- Fastest car all weekend
- Extremely High Grip
- Qualified 8th due to Electrical Issues





Shock Settings

Front

Rear

Shock Length: 66
Shock Length: 65
Gap: 2.5
Gap: 2
Piston: 3
Piston: 3
Oil weight: 50
Oil weight: 50
Oil Compensator: Foam
Oil Compensator: Foam
Shock Location* (upper): 2
Shock Location* (upper): 2
Shock Location* (lower): 1
Shock Location* (lower): 1
Spring Brand: Integy C22
Spring Brand: Integy C22
Spring Weight/Color: Red
Spring Weight/Color: Blue

* Shock location numbers taken from outside to inside, top to bottom.


Suspension Geometry Settings

Front

Rear

Toe: 0 deg
Toe: Block 2-2-9
Ackerman: 38.5

Camber: 2
Camber: 2
Caster/Carrier: 3 deg Carrier

Anti-Dive: 2 deg
Anti-Squat:
Upper Link* (inside): 4
Upper Link* (inside): 7
Upper Link* (outside): Thick Spacer
Upper Link* (outside): 2
Lower Arm Position:
Lower Arm Position:
Sway Bar:
Sway Bar:
Ride Height: 4mm
Ride Height: 5mm
Suspension Droop:
Suspension Droop:

Wheelbase Length: 259.5mm
in/front - 2
in/front - 3
out/front - .5
out/front - 1.5
in/rear - 0
in/rear - 0
out/rear - 0
out/rear - 2
* Upper link location numbers taken from outside to inside, top to bottom.


Tires

Front

Rear

Brand: HPI
Brand: HPI
Type: 33R
Type: 33R
Wheel: HPI 5-Spoke
Wheel: HPI 5-Spoke
Insert: HPI Green
Insert: HPI Green
Diameter: 63mm
Diameter: 63mm

Traction Compound:
Percentage -
Percentage -
